| Footprint | 41.5” x 39.5” (1,054 mm x 1,004 mm) |
| Weight (tank empty) | 550 lb (250 kg) |
| Height (Lid Closed) | 56.5” (1,435 mm) |
| Height (Lid Open) | 73.0” (1,854 mm) |
| Operating Weight (with water in tank) | 750 lb (340 kg) |
| X-Y Cutting Travel | 12.0” x 12.0” (304 mm x 304 mm) |
| Z-Axis Travel | 1.0” (25 mm) |
| Table Size | 14.5” x 15.25” (368 mm x 393 mm) |
| Maximum Supported Material Load | 50 lbs/sq ft (244 kg/sq m) |
| Maximum Supported Material Load | 230-240 VAC, single phase, 30A, 50/60 Hz |
| Speed | 100 in/min (2,540 mm/min) |
| Linear Positional Accuracy | ±0.005” (±0.127 mm) |
| Repeatability | ±0.003” (±0.076 mm) |
| Pump Horsepower | 5 HP (3.7 kW) |
| Output Pressure | 30,000 psi (2,068 bar) |
| Orifice and Flow | 0.008” / 0.25 gpm (0.2 mm / 0.95 lpm) |
DESCRIPTION
They say that good things come in small packages, and the small waterjet PROTOMAX® built by OMAX is no exception! Compact and versatile, this abrasive waterjet cutting center offers maximum performance for its size, production reliability and low operating costs.
The compact machine footprint of 41.5″ x 39.5″ (1,054 mm x 1,004 mm) combined with its comprehensive versatility makes the small waterjet PROTOMAX an ideal abrasive waterjet cutting machine for prototyping, light commercial applications, educational settings or as a complement to a larger machine shop.
With the small waterjet PROTOMAX, the possibilities are endless: cut nearly any material, including aluminum, titanium, stone, carbon fiber, and G10 composite up to 1-inch (2.5 cm) cutting thickness. Work material is submerged underwater for quiet cutting that won’t disrupt your workspace.When it comes to power and performance, the PROTOMAX really packs a punch. A best-in-class 5HP pump generating 30,000 PSI pressure and proven direct drive pump technology make the PROTOMAX the most efficient waterjet cutting tool for its size.
The PROTOMAX is as efficient as it is reliable. The pump stops during non-cutting traverses to save electricity, garnet usage is minimized with optimal pressure and cutting models, plus the system is configured with a variable frequency drive for high-performance motor control that reduces energy consumption and maintenance.
Equipped with castors, the PROTOMAX is a true mobile abrasive waterjet cutting center designed for small spaces. It can even fit through a standard doorway! A snap to install, simply wheel the unit into place and plug it into a standard 240VAC outlet. That’s all there is to it!
Set up your machine in no time thanks to the preconfigured OMAX Intelli-MAX® Proto system, advanced CAD software designed for abrasive waterjet systems. Complete with a user-friendly interface, you’ll have everything at your fingertips to get cutting right away!
Spark & Co. has been a distributor of OMAX waterjet cutting systems (PROTOMAX®, GLOBALMAX®, MAXIEM® and OMAX® series) for over a decade. No one is better equipped to meet your needs in waterjet, Laser (2D laser, Tube Laser, Shaping and Finishing.
For more information : https://www.omax.com/protomax-waterjet
